Welcome to

Welcome to ICONICS GENESIS64™, an advanced HMI/SCADA solution suite designed for Microsoft operating systems. ICONICS GENESIS64 suite delivers unparalleled performance with OPC, BACnet, Modbus, and open standard database connectivity. The GENESIS64 suite provides connectivity from plant floor and building facilities to corporate business systems. Designed to leverage 64-bit and OPC UA technologies, GENESIS64 allows operators, executives, and IT professionals to integrate real-time manufacturing, energy, and business information into a secure and unified web-enabled visualization dashboard.

GENESIS64 was designed from the ground up to use the latest technologies including:

  • Entirely built using Microsoft .NET technology

  • Windows Presentation Foundation (WPF)

  • 3D Hardware-accelerated Visualization

  • Windows Communication Foundation (WCF)

  • OPC Unified Architecture (OPC UA)

  • Windows User Access Control (UAC)

  • Search & Organize

  • Bing, Google and Esri Map Integration

  • Natural User Interface/Multitouch

ICONICS GENESIS64 is:

  • OPC UA Integrated

  • BACnet Integrated

ICONICS GENESIS64 suite includes the following products:

The following optional ICONICS products are also available via separate installation media:

Click HERE for further overview of GENESIS64's Architecture.

GENESIS64 is a substantial suite of applications. You can perform all system configurations in the Workbench. From your Alarm Server configuration to your system Security, and HMI displays, you can do it all within the Workbench.

Workbench

As is shown in the illustration above, you can connect to and configure many different GENESIS64 applications within the Workbench. Aside from the services and their configurations, there are containers for viewing different types of data in the Workbench. These containers are also controls that you can add into GraphWorX64 displays. Unlike GENESIS32, where containers are standalone applications, most containers in GENESIS64 can only be configured and run within Workbench. The GraphWorX64 container is the only one in the GENESIS64 suite that allows for configuration and runtime without going into the Workbench. Like the Workbench, these you can configure and even go into runtime to view data in these containers.

OPC and Data Communication

GENESIS64 supports OPC specifications including OPC Data Access (OPC DA), OPC Alarms and Events (OPC AE), OPC Historical Data Access (OPC HDA), OPC Security, OPC Batch, OPC XML-DA, and OPC Complex Data. On top of these OPC specifications, GENESIS64 also supports the OPC Unified Architecture (OPC UA). For more information, refer to the OPC Overview and OPC and GENESIS64 topics.

In addition, GENESIS64 also supports communication from other industry standard communication protocols such as Simple Network Management Protocol (SNMP), and BACnet which is commonly found in building automation. For more information, refer to the Overview of BACnet and Introduction to SNMP topics.

Platform Services

Platform Services within ICONICS software products perform a variety of functions including the following:

FrameWorX and Configuration Services

The Application FrameWorX and Configuration Services components are the core to the communications of the GENESIS64 client applications. Specifically, all communications from the GENESIS64 clients, such as the Workbench and GraphWorX64, go through a communications layer comprised of the Application FrameWorX and Configuration Services. Also, all of the Licensing, Security, and OPC Data go through the Application FrameWorX.

In contrast, all of the configuration pieces of the Hyper Historian, Unified Data Manager, AlarmWorX64 Server, and so on, go through their respective Configuration services.

For more about FrameWorX64, refer to the FrameWorX64 Server topic.
